Capsule Pressure Gauge
Category : PRESSURE
Sub Category :
Pressure Gauge
Share:
Specification
| Standard | ASME B40.100 / EN 837-1 / IS-3624 |
| Dial Size | 63 mm (2.5”), 100 mm (4”), 115 mm (4.5”), 150 mm (6”) |
| Features | Low pressure measurement |
| Stainless steel construction | |
| Suitable for gases and liquid application | |
| Protection IP54, IP65 and IP66 | |
| Suitable for corrosive environments | |
| Standard zero adjustment | |
| Ranges | 0 ... 60 mmWC up to 0 ... 6000 mmWC |
| Construction | Open front cylindrical case, with blow out disc at the back and vent plug on top |
| Measuring principle | Capsule |
| Connection location | Lower, Centre back |
| Pressure connection | Stainless steel 316 |
| Capsule | Stainless steel 316 |
| Case/bayonet ring | Stainless steel 304, optional 316L |
| Window | Instrument glass, optional laminated safety glass or acrylic glass |
| Dial | Aluminum, black markings on white background |
| Pointer | Aluminum, black |
| Movement | Stainless steel |
| Process connection | 1/4” 3/8” 1/2” BSP / NPT (M) , M20x1.5 (M) Others on request |
| Overpressure limit | 130 % F.S., short time. |
| Accuracy | 2.0 % F.S. |
| Ambient temperature | -25 ... 60 °C (-13 ... 140 °F) |
| Medium temperature | Max. 100 °C (212 °F) |
| Storage temperature | -40 ... 65 °C (-40 ... 150 °F) |
| Effect | Max. 0,5 % / 10 K |
| Protection according | IP54 / IP65 / IP66 |
| Accessories, options | Valves, Pressure limiters, Cooling towers, etc |
